Features

• Powered by Yamaha's MZ80; 79cc, air-cooled (fan assist), OHV, 2-valve, 4-stroke, single cylinder engine with transistor controlled (TC) ignition.
• Auto decompression system reduces engine compression to provide a light recoil starter pull for effortless manual starting.
• Cast iron cylinder liner provides excellent heat dissipation & extends service life.
• Pulse Width Modulation provides super "clean" power. As clean or cleaner than the power you get from a household receptacle.
• Rated AC output for continuous use is 1,600 watts / 13.3 amps with a single unit.
• When "twinned" with another EF2000iST rated AC output for continuous use is 3,000 watts / 25 amps. (note: requires accessory parallel terminal kit available at extra cost (part number: 7PB-YH579-80-00).
• Neutral floating.
• Non-fuse type circuit breaker (NFB) prevents internal circuit damage in the event of an over load.
• Yamaha's Noise Block body design features a moulded casing and noise-absorbing glass wool to provide ultra-quiet operation.
• Smart Throttle / Economy Control automatically adjusts engine speed to match the load, saving fuel, reducing noise and engine wear.
• Manual choke
• Yamaha's Oil Watch Warning System automatically shuts off the engine when oil level is low and will not re-start until oil is added, preventing costly engine damage and enhancing long-term durability.
• Indicator lights for AC power output, low oil and AC overload.
• Washable foam air filter reduces maintenance costs
• 12 Volt DC output and cables for charging RV, auto and marine 12-volt batteries (12V / 6.5A).
• On-off fuel petcock lets you shut off the gas to run the carb dry for storage, helping to prevent stale fuel problems, which are becoming more common with ethanol based fuels.
• Large fuel fill hole and sealable vent on gas cap for easy filling and transporting. Fuel gauge is standard
• Cleanable spark arrestor stops the possibility of sparks exiting from the exhaust.
• Rubber feet isolate vibration for smoother operation and reduced noise.
• Suitcase style handle and light weight (21 kg / 46 lbs.) make the EF2000iST very portable.
• CSA approved (Canadian Standards Association)
• EPA & CARB Emission Engine Durability Rating. Yamaha generators have the longest emission engine durability ratings issued by the Environmental Protection Agency and the California Air Resources Board.
• 3-year warranty for "residential / home" use or "commercial use."

Type
Brushless Inverter
Maximum AC Output (watts / amperes)
2000 W / 16.7 A
Rated AC Output (watts / amperes) - Continuous Use
1600 W / 13.3 A
Rated AC Output (watts / amperes) - Continuous Use – "Twinned" Units
3000 W / 25 A
AC Voltage & Frequency (HZ)
120 V / 60 HZ
Voltage Regulator
Inverter (Pulse Width Modulation)
Neutral
Floating
DC Output (volts / amp)
12 V / 6.5 A
Engine Model
MZ80, 79cc, air-cooled (fan assist), OHV, 2-valve, 4-stroke
Starting System
Manual Recoil
Ignition
Transistor Controlled Ignition (TCI)
Recommended Fuel
87 octane regular gasoline
Engine Oil Capacity
0.42L
General
L x W x H mm (in)
490 x 280 x 455 (19.3 x 11 x 17.9)
Dry Weight
21kg / (46lb)
Fuel Tank Capacity (L)
4.2
Operating Hours (@ 1 / 4 load)
**10.5 hrs
Operating Hours (@ rated load)
**4.2 hrs
Noise Level (@ 7 metres)
**51.5 - 61dB
Technical Features
Non-Fuse Circuit Breaker System (NFB)
Standard
Pilot Lamp (AC output)
Standard
Warning Lamps (overload / low oil)
Standard
Smart Throttle / Economy Control
Standard
Oil Watch Warning System
Standard
Fuel Level Gauge
Standard
Noise Block (enclosed engine design)
Standard
Spark Arrestor
Standard
Accessories
DC Charging Cable
Standard
Warranty
Private Use†
3-years limited
Commercial Use†
3-years limited
